Get all Running Runbook Jobs
This post I’ll show how to get all Running Runbook jobs.
ConvertTo-SCOObject
I used the ConvertTo-SCOObject function Robert Hearn posted here to parse the xml response from the GET call.
function ConvertTo-SCOObject {
\[CmdletBinding()\]
PARAM (
\[Parameter(Mandatory=$true)\]
\[String\] $XmlFeed
)
$xml =\[xml\]$XmlFeed
$ns = New-Object Xml.XmlNamespaceManager $xml.NameTable
$ns.AddNamespace( "d", "http://schemas.microsoft.com/ado/2007/08/dataservices")
$ns.AddNamespace( "m", "http://schemas.microsoft.com/ado/2007/08/dataservices/metadata")
$ns.AddNamespace( "def", "http://www.w3.org/2005/Atom")
$objarray = @()
$entryNodes = $xml.SelectNodes("//def:entry",$ns)
foreach ($entryNode in $entryNodes)
{
$obj = New-Object PSObject
$objectType = $entryNode.SelectSingleNode(".//def:category", $ns).GetAttribute("term")
$obj | add-member Noteproperty -Name "Object Type" -Value $objectType.Split(".")\[-1\]
$propertiesNode = $entryNode.SelectSingleNode(".//m:properties", $ns)
foreach($propertyNode in $propertiesNode.ChildNodes)
{
$obj | add-member Noteproperty -Name $propertyNode.LocalName -Value $propertyNode.get_InnerText()
}
$links = $entryNode.SelectNodes(".//def:link", $ns)
foreach ($link in $links)
{
$obj | add-member NoteProperty -Name $link.title -Value $link.href
}
$objarray += $obj
}
return $objarray
odata URL
Due to the paging limits on the web service collections (Jobs being 500), I used this method for filtering the results. The most important part of this GET is building the query into the odata URI. You can build in filters, select statements, etc. on the Web Service collections shown like this.
http://scorch.domain:81/Orchestrator2012/Orchestrator.svc/Jobs()?$filter=Status eq 'Running'
\\_______________________________________________________/\____/\_________________________/
| | |
service root URI resource path query options
Putting this into practice w/ SCOrch, you can query the Jobs collection, filter for Jobs that have a Status of “Running”, and select the fields you would like to return – Id,RunbookId,LastModifiedTime,Status.
"http://scorch.domain:81/Orchestrator2012/Orchestrator.svc/Jobs()?`$filter=Status eq 'Running'&`$select=Id,RunbookId,LastModifiedTime,Status"
So you can use this on any of the collections to filter results i.e. Jobs, Runbooks, RunbookInstances, Statistics, etc.
SCOrch GET Request
The GET request would look like this.
$creds = Get-Credential("domain\\username")
$XmlFeed = $null
$count = 0
$url = "http://scorch.domain:81/Orchestrator2012/Orchestrator.svc/Jobs()?`$filter=Status eq 'Running'&`$select=Id,RunbookId,LastModifiedTime,Status"
$request = \[System.Net.HttpWebRequest\]::Create($url)
$request.Credentials = $creds
$request.Timeout = 60000
$request.ContentType = "application/atom+xml,application/xml"
$request.Method = "GET"
$response = $request.GetResponse()
$requestStream = $response.GetResponseStream()
$readStream=new-object System.IO.StreamReader $requestStream
$XmlFeed = $readStream.ReadToEnd()
$readStream.Close()
$response.Close()
Parsing the GET Response
Using the ConvertTo-SCOObject function, you can then parse the response and set your variables and get a count of the running runbooks.
ConvertTo-SCOObject -XmlFeed $XmlFeed | %{$count++}
$Id = ConvertTo-SCOObject -XmlFeed $XmlFeed | %{$_.Id}
$RunbookId = ConvertTo-SCOObject -XmlFeed $XmlFeed | %{$_.RunbookId}
$LastModifiedTime = ConvertTo-SCOObject -XmlFeed $XmlFeed | %{$_.LastModifiedTime}
$Status = ConvertTo-SCOObject -XmlFeed $XmlFeed | %{$_.Status}
Complete Script Block
Here is the complete script for getting all Running Runbook Jobs. Highlighted fields would need to be updated per your environment.
function ConvertTo-SCOObject {
\[CmdletBinding()\]
PARAM (
\[Parameter(Mandatory=$true)\]
\[String\] $XmlFeed
)
$xml =\[xml\]$XmlFeed
$ns = New-Object Xml.XmlNamespaceManager $xml.NameTable
$ns.AddNamespace( "d", "http://schemas.microsoft.com/ado/2007/08/dataservices")
$ns.AddNamespace( "m", "http://schemas.microsoft.com/ado/2007/08/dataservices/metadata")
$ns.AddNamespace( "def", "http://www.w3.org/2005/Atom")
$objarray = @()
$entryNodes = $xml.SelectNodes("//def:entry",$ns)
foreach ($entryNode in $entryNodes)
{
$obj = New-Object PSObject
$objectType = $entryNode.SelectSingleNode(".//def:category", $ns).GetAttribute("term")
$obj | add-member Noteproperty -Name "Object Type" -Value $objectType.Split(".")\[-1\]
$propertiesNode = $entryNode.SelectSingleNode(".//m:properties", $ns)
foreach($propertyNode in $propertiesNode.ChildNodes)
{
$obj | add-member Noteproperty -Name $propertyNode.LocalName -Value $propertyNode.get_InnerText()
}
$links = $entryNode.SelectNodes(".//def:link", $ns)
foreach ($link in $links)
{
$obj | add-member NoteProperty -Name $link.title -Value $link.href
}
$objarray += $obj
}
return $objarray
}
$creds = Get-Credential("domain\\username")
$XmlFeed = $null
$count = 0
$url = "http://scorch.domain:81/Orchestrator2012/Orchestrator.svc/Jobs()?`$filter=Status eq 'Running'&`$select=Id,RunbookId,LastModifiedTime,Status"
$request = \[System.Net.HttpWebRequest\]::Create($url)
$request.Credentials = $creds
$request.Timeout = 60000
$request.ContentType = "application/atom+xml,application/xml"
$request.Method = "GET"
$response = $request.GetResponse()
$requestStream = $response.GetResponseStream()
$readStream=new-object System.IO.StreamReader $requestStream
$XmlFeed = $readStream.ReadToEnd()
$readStream.Close()
$response.Close()
ConvertTo-SCOObject -XmlFeed $XmlFeed | %{$count++}
$Id = ConvertTo-SCOObject -XmlFeed $XmlFeed | %{$_.Id}
$RunbookId = ConvertTo-SCOObject -XmlFeed $XmlFeed | %{$_.RunbookId}
$LastModifiedTime = ConvertTo-SCOObject -XmlFeed $XmlFeed | %{$_.LastModifiedTime}
$Status = ConvertTo-SCOObject -XmlFeed $XmlFeed | %{$_.Status}
A few good resources for working with the Orchestrator Web Service.
